3DEXPERIENCE® DraftSight is a powerful 2D drafting solution that combines data management, project planning and collaboration in a single platform.

Extend DraftSight capabilities by accessing a vast set of concept-to-market solutions that work together seamlessly.

Securely share data and collaborate from anywhere, at any time, and on any device combining structured and unstructured collaboration.

Effortlessly connect people and data while eliminating licensing and user management challenges.

Specifications

Annotation Monitor

DraftSight’s associative dimensioning tool is a fantastic way to make sure your dimensions update whenever your geometry changes. But sometimes these associative dimensions become disassociated from their entities. DraftSight 2023 addresses this issue with the introduction of the new Annotation Monitor feature. When it’s enabled, any dimension that has lost its association will display a small, yellow, warning icon next to the offending dimension.

Page Layout Manager

The DraftSight 2023 release includes one of our users' most requested features. The new Page Layout Manager will save you time setting up your print or plot settings. Instead of creating and managing an external print configuration file, you can save all your print or plot parameters in a named setup that is saved inside your drawing or template file.

Contextual Ribbon Tab

Access to the commands you need for your current workflow has been made easier in DraftSight 2023 with Contextual Ribbons. Now, instead of a dialog box cluttering your editor, the Ribbon will display a new, active tab that is appropriate for your current task.

HomeByMe Improvements

DraftSight has provided an add-in for years that acts as a bridge between a HomeByMe project and a functional 2D CAD drawing. That interface has been updated in 2023 to provide a more intuitive user experience. And the underlying program architecture has been completely revamped to give our customers even greater functionality.
